ATEN 2-Port USB 3.1 Gen 1 DisplayPort 1.1 KVMP™ Switch with Speaker (KVM cables included)
2-Port USB 3.1 Gen 1 DisplayPort 1.1 KVMP™ Switch with Speaker (KVM cables included)
- Delivered by tomorrow or collect today (order Mon-Fri Delivery times 07:00 - 17:00) *T&C's Apply
- Including shipping costs on orders over R1500
- Pick up at TrueTech.co.za collection point is possible
- 7 days to change your mind and free returns
- Excellent customer service
Description
The ATEN CS1912 2-Port USB 3.0 DisplayPort KVMP™ Switch provides the latest innovations in desktop KVM switching technology to meet the increasing demand of higher video quality and file transfer rates on modern computers. The CS1912 provides superior resolutions up to 3840 x 2160 @ 30 Hz, a SuperSpeed USB 3.1 Gen 1 hub with 5 Gbps transfer rates and enhanced user-friendly operations.
1 x CS1912 2-Port USB 3.0 DisplayPort KVMP™ Switch
2 x LIN5-20K1-K14G DisplayPort Cables
2 x LIN6-11C1-E12G USB 3.0 Cables
2 x LIN5-0205-21CG Audio Cables
1 x 0AD8-8005-40MG Power Adapter
1 x User Instructions
Additional information
| Number of computers controlled | 2 |
|---|---|
| Brand | Aten |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | DisplayPort |
| DC-in jack | Yes |
| Maximum resolution | 3840 x 2160 pixels |
| HDCP | Yes |
| Rack mounting | No |
| Product colour | Black, Grey |
| Housing material | Metal, Plastic |
| Built-in display | No |
| Operating temperature (T-T) | 0 – 50 °C |
| Storage temperature (T-T) | -20 – 60 °C |
| Operating relative humidity (H-H) | 0 – 80% |
| Width | 88 mm |
| Depth | 210 mm |
| Height | 55.5 mm |
| Weight | 1.36 kg |
| Harmonized System (HS) code | 85176200 |
| Console ports | DisplayPort, USB A |
| Console USB ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| HD type | 4K Ultra HD |
| Video bandwidth | 30 Hz |
| LED indicators | Yes |
| Push button | Yes |
| Hot keys | Yes |
| Power source | DC |
| Power consumption (typical) | 2 W |
| Scan interval | 1,99 s |
| USB hub | Yes |
| Audio connections | Yes |
| Headphone outputs | 4 |
| Automatic switching | Yes |
| Output voltage | 5 V |
| External power adapter | Yes |
| DisplayPorts quantity | 3 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-B ports quantity | 2 |
| Package width | 100 mm |
| Package depth | 283 mm |
| Package height | 173 mm |
| Package weight | 1.77 kg |
| Master (outer) case net weight | 6.8 kg |
| Master (outer) case width | 292 mm |
| Master (outer) case length | 517 mm |
| Master (outer) case height | 194 mm |
| Master (outer) case gross weight | 9.35 kg |
| Products per master (outer) case | 5 pc(s) |
| Compliance certificates | RoHS |
